Load Cells
Please add to cart to keep it or exit the configuration
The LC8313, LC8400 and LC8450 Series Donut Load Cells are a space saving solution to applications requiring a large through-hole with limited space. With their rugged construction ...
Read More
This product has variations available for quick shipping.
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Through hole (ID)/ Threaded hole dimension | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|
LC8400-200-100K
C$1,195.00
1
In Stock
|
100,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
4"
|
2.00'"
|
2"
|
Cable
|
5 ft
|
|
LC8400-213-200K
C$1,195.00
2
In Stock
|
200,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
4"
|
2.13"
|
2"
|
Cable
|
5 ft
|
LC8400-213-50K
C$1,050.00
6
In Stock
|
50,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
4"
|
2.13"
|
1"
|
Cable
|
5 ft
|
LC8400-200-25K
C$1,050.00
5
In Stock
|
25,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
4"
|
2.00'"
|
1"
|
Cable
|
5 ft
|
LC8400-200-50K
C$1,050.00
2
In Stock
|
50,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
4"
|
2.00'"
|
1"
|
Cable
|
5 ft
|
Low profile load cells are basically compression and tension/compression load cells. Mounting holes and female threads provide easy installation. Used frequently in weighing resear...
Read More
This product has variations available for quick shipping.
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Through hole (ID)/ Threaded hole dimension | Height | Connection Type |
|---|---|---|---|---|---|---|---|---|---|
|
LCHD-500
C$1,165.00
5
In Stock
|
500 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
3"
|
3⁄8-24 UNF
|
1"
|
MIL-26482-I 10-6P
|
|
LCHD-20K
C$1,655.00
5
In Stock
|
20,000 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
6"
|
1 1⁄2-12 UNF
|
1.8"
|
MIL-5015-I 14S-6P
|
|
LCHD-25
C$1,165.00
3
In Stock
|
25 lbf
|
lbf
|
Tension/Compression
|
±0.2%
|
2 mV/V
|
2.5"
|
1/4-28 UNF
|
0.8"
|
MIL-26482-I 10-6P
|
|
LCHD-2K
C$1,165.00
3
In Stock
|
2,000 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
3.5"
|
1⁄2-20 UNF
|
1"
|
MIL-26482-I 10-6P
|
|
LCHD-100
C$1,165.00
4
In Stock
|
100 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
3"
|
3⁄8-24 UNF
|
1"
|
MIL-26482-I 10-6P
|
SPECIFICATIONS Excitation: 10 Vdc (15 Vdc max) Output: 3 mV/V ±0.25% 5-Point Calibration: 0%, 50%, 100%, 50%, 0% in compression ...
Read More
This product has variations available for quick shipping.
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Through hole (ID)/ Threaded hole dimension | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|
|
LC412-15K
C$1,535.00
5
In Stock
|
15,000 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
4"
|
1-14 UNF
|
2"
|
MIL-26482-I 10-6P
|
Not Applicable
|
|
LC412-10K
C$1,430.00
2
In Stock
|
10,000 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
3.75"
|
3⁄4-16 UNF
|
1.5"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LC412-25K
C$1,535.00
1
In Stock
|
25,000 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
4"
|
1-14 UNF
|
2"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LC412-2K
C$1,135.00
1
In Stock
|
2,000 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
3.5"
|
1⁄2-20 UNF
|
1.5"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LC412-3K
C$1,135.00
1
In Stock
|
3,000 lbf
|
lbf
|
Tension/Compression
|
±0.1%
|
3 mV/V
|
3.5"
|
1⁄2-20 UNF
|
1.5"
|
MIL-26482-I 10-6P
|
Not Applicable
|
The LCGD Series miniature low profile load cells are compression load cells with excellent long term stability. An all stainless steel construction assures reliability in severe in...
Read More
This product has variations available for quick shipping.
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|
|
LCGD-50K
C$1,105.00
3
In Stock
|
50,000 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
3"
|
1.5"
|
Cable
|
5 ft
|
|
LCGD-10K
C$840.00
25
In Stock
|
10,000 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
1.5"
|
0.63"
|
Cable
|
5 ft
|
|
LCGD-250
C$785.00
5
In Stock
|
250 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
1.25"
|
0.39"
|
Cable
|
5 ft
|
|
LCGD-25
C$930.00
12
In Stock
|
25 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
1"
|
0.62"
|
Cable
|
5 ft
|
|
LCGD-2K
C$730.00
12
In Stock
|
2,000 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
1.25"
|
0.39"
|
Cable
|
5 ft
|
S-Beam load cells that receive tension or compression output readings. Applications include tank weighing, hoppers, suspended loads and truck scales. S-Beam load cells provide supe...
Read More
This product has variations available for quick shipping.
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | Height | Width | Length | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|
|
LC101-20K
C$1,100.00
1
In Stock
|
20,000 lbf
|
lbf
|
Tension
|
±0.03%
|
3 mV/V
|
4.3"
|
1.5"
|
3"
|
Cable
|
15 ft
|
LC101-30K
C$1,330.00
4
In Stock
|
30,000 lbf
|
lbf
|
Tension
|
±0.03%
|
3 mV/V
|
4.3"
|
2"
|
4"
|
Cable
|
15 ft
|
|
LC101-5K
C$730.00
7
In Stock
|
5,000 lbf
|
lbf
|
Tension
|
±0.03%
|
3 mV/V
|
3.5"
|
1"
|
2.5"
|
Cable
|
15 ft
|
|
LC101-3K
C$600.00
6
In Stock
|
3,000 lbf
|
lbf
|
Tension
|
±0.03%
|
3 mV/V
|
3.5"
|
1"
|
2.5"
|
Cable
|
15 ft
|
|
LC101-1K
C$510.00
29
In Stock
|
1,000 lbf
|
lbf
|
Tension
|
±0.03%
|
3 mV/V
|
3"
|
1"
|
2"
|
Cable
|
30 ft
|
Small in size and capable of providing highly accurate readings, the LCFD Series miniature load cells are precision subminiature load cells for industrial applications requiring a ...
Read More
This product has variations available for quick shipping.
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|
|
LCFD-1K
C$1,165.00
4
In Stock
|
1,000 lbf
|
lbf
|
Tension/Compression
|
±0.2%
|
2 mV/V
|
1"
|
1.31"
|
Cable
|
5 ft
|
|
LCFD-25
C$1,165.00
3
In Stock
|
25 lbf
|
lbf
|
Tension/Compression
|
±0.15%
|
2 mV/V
|
1"
|
1.14"
|
Cable
|
5 ft
|
|
LCFD-250
C$1,165.00
4
In Stock
|
250 lbf
|
lbf
|
Tension/Compression
|
±0.2%
|
2 mV/V
|
1"
|
1.31"
|
Cable
|
5 ft
|
|
LCFD-50
C$1,165.00
9
In Stock
|
50 lbf
|
lbf
|
Tension/Compression
|
±0.15%
|
2 mV/V
|
1"
|
1.14"
|
Cable
|
5 ft
|
|
LCFD-10
C$1,165.00
3
In Stock
|
10 lbf
|
lbf
|
Tension/Compression
|
±0.15%
|
2 mV/V
|
0.75"
|
1"
|
Cable
|
5 ft
|
The LCGB Series comprises miniature low-profile compression load cells with excellent long-term stability. An all stainless steel construction ensures reliability in harsh ...
Read More
This product has variations available for quick shipping.
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|
|
LCGB-50K
C$1,105.00
3
In Stock
|
50,000 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
3"
|
1.5"
|
Cable
|
5 ft
|
|
LCGB-10K
C$840.00
8
In Stock
|
10,000 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
1.5"
|
0.63"
|
Cable
|
5 ft
|
|
LCGB-2K
C$730.00
4
In Stock
|
2,000 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
1.25"
|
0.39"
|
Cable
|
5 ft
|
|
LCGB-20K
C$995.00
9
In Stock
|
20,000 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
2"
|
1"
|
Cable
|
5 ft
|
|
LCGB-5K
C$840.00
10
In Stock
|
5,000 lbf
|
lbf
|
Compression
|
±0.25%
|
2 mV/V
|
1.5"
|
0.63"
|
Cable
|
5 ft
|
Small in size and capable of providing highly accurate readings, the LCMFD Series load cells are precision subminiature load cells for industrial applications requiring a small siz...
Read More
This product has variations available for quick shipping.
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|
|
LCMFD-50N
C$1,140.00
10
In Stock
|
50 N
|
N
|
Tension/Compression
|
±0.15%
|
1.5 mV/V
|
0.75"
|
1"
|
Cable
|
5 ft
|
LCMFD-2KN
C$1,140.00
3
In Stock
|
2,000 N
|
N
|
Tension/Compression
|
±0.2%
|
2 mV/V
|
1"
|
1.31"
|
Cable
|
5 ft
|
LCMFD-500N
C$1,140.00
6
In Stock
|
500 N
|
N
|
Tension/Compression
|
±0.15%
|
2 mV/V
|
1"
|
1.14"
|
Cable
|
5 ft
|
LCMFD-5KN
C$1,140.00
2
In Stock
|
5,000 N
|
N
|
Tension/Compression
|
±0.2%
|
2 mV/V
|
1"
|
1.31"
|
Cable
|
5 ft
|
LCMFD-100N
C$1,140.00
3
In Stock
|
100 N
|
N
|
Tension/Compression
|
±0.15%
|
2 mV/V
|
1"
|
1.14"
|
Cable
|
5 ft
|
OMEGA’s LC702 Series Tension Links have a 6 ft (2 m) cable, and the LC712 Series have an integral connector. Both series are all stainless steel high capacity in-line tension load ...
Read More| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|
LC712-10K
C$1,295.00
9
In Stock
|
10,000 lbf
|
lbf
|
Tension
|
±0.1%
|
2 mV/V
|
3"
|
5.5"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LC712-20K
C$1,295.00
4
In Stock
|
20,000 lbf
|
lbf
|
Tension
|
±0.1%
|
2 mV/V
|
3"
|
6.5"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LC712-300K
C$4,890.00
2
In Stock
|
300,000 lbf
|
lbf
|
Tension
|
±0.1%
|
2 mV/V
|
5.56"
|
12.75"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LC712-30K
C$1,295.00
1
In Stock
|
30,000 lbf
|
lbf
|
Tension
|
±0.1%
|
2 mV/V
|
3"
|
6.5"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LC702-10K
C$1,295.00
1
In Stock
|
10,000 lbf
|
lbf
|
Tension
|
±0.1%
|
2 mV/V
|
3"
|
5.5"
|
Cable
|
6 ft
|
The LC8250 Series Donut Load Cell is an economical solution to applications requiring a through-hole design. With its extremely low profile and compact design, this load cell is id...
Read More| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Through hole (ID)/ Threaded hole dimension | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|
LC8250-500-15K
C$1,020.00
1
In Stock
|
15,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
2.5"
|
0.500"
|
1"
|
Cable
|
5 ft
|
LC8250-625-50K
C$1,020.00
1
In Stock
|
50,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
2.5"
|
0.625"
|
1"
|
Cable
|
5 ft
|
LC8250-875-20K
C$1,020.00
2
In Stock
|
20,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
2.5"
|
0.875"
|
1"
|
Cable
|
5 ft
|
LC8250-875-30K
C$1,020.00
1
In Stock
|
30,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
2.5"
|
0.875"
|
1"
|
Cable
|
5 ft
|
LC8250-1.00-100K
C$1,165.00
3
In Stock
|
100,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
2.5"
|
1.00"
|
1"
|
Cable
|
5 ft
|
The LC8300 Series Donut Load Cell is an economical solution to applications requiring a through-hole design. With its extremely low profile and compact design, this load cell is id...
Read More| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Through hole (ID)/ Threaded hole dimension | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|
LC8300-750-30K
C$1,020.00
1
In Stock
|
30,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
3"
|
0.750"
|
1"
|
Cable
|
5 ft
|
LC8300-875-30K
C$1,020.00
2
In Stock
|
30,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
3"
|
0.875"
|
1"
|
Cable
|
5 ft
|
LC8300-500-40K
C$1,020.00
4
In Stock
|
40,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
3"
|
0.500"
|
1"
|
Cable
|
5 ft
|
LC8300-1.25-3K
C$755.00
1
In Stock
|
3,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
3"
|
1.25"
|
1"
|
Cable
|
5 ft
|
LC8300-1.13-1K
C$755.00
1
In Stock
|
1,000 lbf
|
lbf
|
Compression
|
±0.5%
|
2 mV/V
|
3"
|
1.13"
|
1"
|
Cable
|
5 ft
|
The LCM402 and LCM412 are also available in standard configurations, with 0-50 to 0-750,000 lb ranges and standard threads. Please see the Read More
| Product Number | Weight Capacity | Measurement Units | Force direction | Linearity | Electrical Output (nominal) | OD | Through hole (ID)/ Threaded hole dimension | Height | Connection Type | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|
LCM412-1K
C$1,125.00
1
In Stock
|
1,000 kgf
|
kgf
|
Compression
|
±0.1%
|
3 mV/V
|
3.5"
|
M12 x 1.75
|
1.5"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LCM402-10K
C$1,520.00
1
In Stock
|
10,000 kgf
|
kgf
|
Compression
|
±0.1%
|
3 mV/V
|
4"
|
M24 x 2
|
2"
|
Cable
|
15 ft
|
LCM402-500
C$1,125.00
1
In Stock
|
500 kgf
|
kgf
|
Compression
|
±0.1%
|
3 mV/V
|
3.5"
|
M12 x 1.75
|
1.5"
|
Cable
|
15 ft
|
LCM412-10K
C$1,520.00
Available
in 8 weeks |
10,000 kgf
|
kgf
|
Compression
|
±0.1%
|
3 mV/V
|
4"
|
M24 x 2
|
2"
|
MIL-26482-I 10-6P
|
Not Applicable
|
LCM412-2.5K
C$1,125.00
Available
in 8 weeks |
2,500 kgf
|
kgf
|
Compression
|
±0.1%
|
3 mV/V
|
3.75"
|
M20 x 1.5
|
1.5"
|
MIL-26482-I 10-6P
|
Not Applicable
|
