Électrodes

29 produits trouvés

Description pH Electrodes OMEGA’s glass-bodied, refillable (RF), combination pH electrodes are for general purpose laboratory measurements. The inert nat... Lire la suite

PHE-1478-1525
Prix Stock Electrode Material pH Range Electrode Type Maximum Temperature Measurement Features
1   En stock
Glass
0 to 14 pH
Flat surface pH electrode
100°C (212°F)
Standard
Disponible dans 9 semaines
Glass
0 to 14 pH
PTFE liquid junction
100°C (212°F)
Standard
Disponible dans 9 semaines
Glass
0 to 14 pH
PTFE liquid junction
100°C (212°F)
HF/Fluoride resistant
Disponible dans 9 semaines
Glass
0 to 14 pH
Ceramic liquid junction electrode
100°C (212°F)
Standard
Disponible dans 9 semaines
Glass
0 to 14 pH
Spear-Point pH electrode
100°C (212°F)
Standard
show More  Charger plus darticles de cette famille ({0}) ...
thumbnail

Description The OMEGA™ PHE/ORE-4580 bypass flow pH system has a modified 1" CPVC or PVDF tee and cable assembly matched to the flat surface pH and ORP electrodes.... Lire la suite

PHE-4580-Series
Prix Stock Electrode Material pH Range Maximum Temperature Measurement Maximum Operating Pressure Features
1   En stock
CPVC
0 to 14 pH
65.5°C (150°F)
50 PSIG
pH Measurement
Disponible dans 7 semaines
CPVC
0 to 14 pH
65.5°C (150°F)
50 PSIG
ORP Measurement
Disponible dans 7 semaines
PVDF
0 to 14 pH
65.5°C (150°F)
50 PSIG
pH Measurement
Disponible dans 7 semaines
CPVC
0 to 14 pH
65.5°C (150°F)
50 PSIG
pH Measurement, Low conductivity
Disponible dans 7 semaines
PVDF
0 to 14 pH
100°C (212°F)
50 PSIG
pH Measurement, Acrylamide Gel
show More  Charger plus darticles de cette famille ({0}) ...

Description OMEGA Engineering offers pH electrodes with integral preamplifiers for laboratory or industrial applications. These electrodes can interface directly with... Lire la suite

PHE6300-5300-2114-1304
Prix Stock Electrode Material Connection Type pH Range Maximum Temperature Measurement Connection Size RTD type Electrical Connection Features
2   En stock
Epoxy-bodied
Not Applicable
0 to 12 pH
80°C (176°F)
Not Applicable
Not Applicable
Not Applicable
Replaceable external battery pack
Disponible dans 6 semaines
CPCV
MNPT mounting thread
0 to 13 pH
80°C (176°F)
3/4
100 Ω Platinum RTD
10 ft Cable
Standard
Disponible dans 6 semaines
Not Applicable
Not Applicable
0 to 13 pH
80°C (176°F)
Not Applicable
Not Applicable
10 ft Cable
Requires external DC power supply of ±1.5 Vdc to ±9 Vdc
1   En stock
Not Applicable
Not Applicable
0 to 13 pH
80°C (176°F)
Not Applicable
1000 Ω Platinum RTD
10 ft Cable
Standard
Disponible dans 6 semaines
Not Applicable
Not Applicable
0 to 13 pH
80°C (176°F)
Not Applicable
100 Ω Platinum RTD
10 ft Cable
Standard
show More  Charger plus darticles de cette famille ({0}) ...
thumbnail

Description OMEGA™ pH and ORP differential probes stay in service and provide accurate measurements under conditions that often render conventional pH probes inoperab... Lire la suite

PHETX-600-Series
Prix Stock Connection Type Maximum Temperature Measurement Maximum Operating Pressure Electrical Connection Features
1   En stock
MNPT mounting thread
95°C (203°F)
100 psig at 65°C (149°F) max
4.6 m (15 ft) Cable
ORP Measurement
Disponible dans 5 semaines
Hot Tap
95°C (203°F)
100 psig at 65°C (149°F) max
4.6 m (15 ft) Cable
ORP Measurement
2   En stock
Hot Tap
95°C (203°F)
100 psig at 65°C (149°F) max
4.6 m (15 ft) Cable
pH Measurement
Disponible dans 5 semaines
Compression Fitting
95°C (203°F)
100 psig at 65°C (149°F) max
4.6 m (15 ft) Cable
ORP Measurement
5   En stock
Compression Fitting
95°C (203°F)
100 psig at 65°C (149°F) max
4.6 m (15 ft) Cable
pH Measurement
show More  Charger plus darticles de cette famille ({0}) ...
thumbnail

Description OMEGA Engineering is pleased to offer a complete line of laboratory pH electrodes. The PHE-4200 Series are gel-filled, combination pH electrodes with a un... Lire la suite

PHE4200
Prix Stock Electrode Material Connection Type pH Range Length Width Maximum Temperature Measurement Electrical Connection Features
Disponible dans 6 semaines
Not Applicable
BNC
0 to 14 pH
150 mm (6 in)
12 mm (0.47 in)
100°C (212°F)
10 ft Cable
General purpose
Disponible dans 6 semaines
Not Applicable
BNC
0 to 14 pH
150 mm (6 in)
12 mm (0.47 in)
100°C (212°F)
13 ft Cable
General purpose
Disponible dans 7 semaines
Epoxy-bodied, Gel filled
BNC
0 to 14 pH
Not Applicable
Not Applicable
100°C (212°F)
750 mm (2.5 ft) Cable
Semi-micro
Disponible dans 7 semaines
Epoxy-bodied, Gel filled
BNC
0 to 14 pH
Not Applicable
Not Applicable
100°C (212°F)
750 mm (2.5 ft) Cable
Flask size
Disponible dans 7 semaines
Epoxy-bodied, Gel filled
US Standard Connector
0 to 14 pH
Not Applicable
Not Applicable
100°C (212°F)
750 mm (2.5 ft) Cable
General purpose
show More  Charger plus darticles de cette famille ({0}) ...
thumbnail

Description Les électrodes à immersion OMEGA™ PHE/ORE-6510, sont conçues pour l'utilisation en ruisseaux, cuves ouvertes et canaux. La surface sensible plate est ... Lire la suite

PHE-6510
Prix Stock Electrode Material Connection Type Length Maximum Temperature Measurement Connection Size RTD type Electrical Connection Features
Disponible dans 6 semaines
CPVC
NPT
75 ft
65°C (150°F)
1/2 in
100 Ω Platinum RTD
Not Applicable
PHE/ORE Measurement
Disponible dans 6 semaines
PVDF
BNC
50 ft
65°C (150°F)
1/2 in
1000 Ω Platinum RTD
Not Applicable
PHE/ORE Measurement
Disponible dans 7 semaines
CPVC
NPT
20 ft
65°C (150°F)
1/2 in
Not Applicable
Not Applicable
PHE/ORE Measurement
Disponible dans 7 semaines
PVDF
NPT
Not Applicable
100°C (212°F)
1/2
Not Applicable
10 ft Cable
pH Measurement, HF/Fluoride resistant
Disponible dans 7 semaines
PVDF
NPT
Not Applicable
100°C (212°F)
1/2
Not Applicable
10 ft Cable
pH Measurement, Low conductivity
show More  Charger plus darticles de cette famille ({0}) ...
thumbnail

Description The PHE-6821 Series electrodes and assemblies feature a retractable design for insertion into tanks and main lines. The assembly, when used with a 1" ... Lire la suite

PHE6820
Prix Stock Electrode Material Connection Type Electrode Type Maximum Temperature Measurement Connection Size RTD type Electrical Connection Features
2   En stock
CPCV
MNPT
Not Applicable
65°C (150°F)
1
100 Ω Platinum RTD
10 ft Cable
Standard
4   En stock
CPCV
MNPT
Not Applicable
65°C (150°F)
1
1000 Ω Platinum RTD
10 ft Cable
Standard
Disponible dans 6 semaines
CPCV
MNPT
Not Applicable
65°C (150°F)
1
3000 Ω Balco
10 ft Cable
Standard
Disponible dans 6 semaines
CPCV
MNPT
Not Applicable
65°C (150°F)
1
Not Applicable
10 ft Stripped Leads
Standard
Disponible dans 6 semaines
CPCV
MNPT
Not Applicable
65°C (150°F)
1
1000 Ω Platinum RTD
15 ft Cable
Standard
show More  Charger plus darticles de cette famille ({0}) ...
thumbnail

Description The PHE-6820B electrode and assembly features a retractable design for insertion into tanks and main lines. The assembly, when used with a 1" full por... Lire la suite

PHE6820B
Prix Stock Electrode Material Connection Type Electrode Type Maximum Temperature Measurement Connection Size Electrical Connection Features
Disponible dans 6 semaines
CPVC
BNC
pH
87°C (190°F)
1
Not Applicable
Fluoride resistant
Disponible dans 6 semaines
CPVC
BNC
pH
87°C (190°F)
1
Not Applicable
Low conductivity
2   En stock
CPVC (457 mm (18\")
BNC
BNC
87°C (190°F)
1
Not Applicable
Not Applicable
Disponible dans 99 semaines
CPVC (610 mm (24\")
BNC
BNC
87°C (190°F)
1
Not Applicable
Not Applicable
3   En stock
CPVC
BNC
pH
87°C (190°F)
1
10 ft Cable
pH Measurement, Flouide, Low Conductivity and Ground Loop
show More  Charger plus darticles de cette famille ({0}) ...
thumbnail

Description Submersion Electrodes The OMEGA™ PHE/ORE-6510B submersible electrodes are designed for use in drums, open tanks and streams. The flat sensing surface is s... Lire la suite

PHE-6510B-Series
Prix Stock Electrode Material Maximum Temperature Measurement Electrical Connection Features
Disponible dans 6 semaines
CPVC
87°C (190°F)
Not Applicable
ORP Measurement, Gold Plated
Disponible dans 7 semaines
CPVC
87°C (190°F)
10 ft Cable
ORP Measurement
Disponible dans 7 semaines
PVDF
100°C (212°F)
10 ft Cable
pH Measurement, HF/Fluoride resistant
Disponible dans 7 semaines
CPVC
87°C (190°F)
Not Applicable
ORP Measurement
Disponible dans 7 semaines
CPVC
100°C (212°F)
Not Applicable
pH Measurement, Low conductivity
show More  Charger plus darticles de cette famille ({0}) ...

Description



Les prix des modèles les plus courants sont donnés dans le tableau "Pour commander".

Pour obtenir les caractéristiques complètes de ces produits, consultez la notice commerciale par le lien en bas de cette page.
Lire la suite

PHE1300-1400-2300
Prix Stock Electrode Material Connection Type pH Range Length Width Electrode Type Maximum Temperature Measurement Electrical Connection Features
Disponible dans 6 semaines
Epoxy
US Standard Connector
±2000 mV
150 mm (5.9 in)
12 mm (0.47 in)
ORP with Polypropylene Liquid Junction
100°C (212°F)
6 ft Cable
Standard
Disponible dans 6 semaines
Epoxy
BNC
0 to 14 pH
150 mm (5.9 in)
12 mm (0.47 in)
Polypropylene liquid junction
100°C (212°F)
10 ft Cable
Standard
Disponible dans 6 semaines
Epoxy
BNC
0 to 14 pH
150 mm (5.9 in)
12 mm (0.47 in)
Polypropylene liquid junction
100°C (212°F)
12 ft Cable
Standard
Disponible dans 6 semaines
Epoxy
BNC
0 to 14 pH
150 mm (5.9 in)
12 mm (0.47 in)
Polypropylene liquid junction
100°C (212°F)
15 ft Cable
Standard
Disponible dans 6 semaines
Epoxy
BNC
0 to 14 pH
150 mm (5.9 in)
12 mm (0.47 in)
Polypropylene liquid junction
100°C (212°F)
4 ft Cable
Standard
show More  Charger plus darticles de cette famille ({0}) ...
